Ring Type Joint - R38 - Soft Iron / Zn Plt - Octagonal
Ring Type Joint - R38 - Soft Iron / Zn Plt - Octagonal

Our Price: $31.70
(Minimum order):  3


Product Code: RTJ-R38-SI-OCT
Qty:

Description

The R-Type ring gasket can be ordered to two different profiles, oval or octagonal in cross-sections. Both types have identical pitch diameter as the flange groove they correspond to. These gaskets are used in pressures up to 5,000 PSI. The octagonal type has a higher sealing coefficient than the oval, therefore being the better gasket of the two. The oval type is the only gasket that will fit a bottom radiused groove. Flanges with flat bottom v-grooves will accept either style. Gaskets that have been torqued initiating a metal-to-metal seal should be discarded and not reused.
